Residential Energy Storage System 405W 415W PERC Half Cell

  • 1
  • 2
  • 3

Brand Name : SUNFiD

Model Number : PV400M1-HP108F

Certification : CE, IEC,CQC,CNAS

Place of Origin : China

MOQ : 50pcs

Price : Negotiable Price

Payment Terms : L/C, T/T, Western Union

Supply Ability : 30000pcs per month

Delivery Time : 10-30 Days

Packaging Details : Wooden Case

Solar Cell : PERC Half Cell Mono-crystalline

Solar Cell size : 182mmx91mm 108Cell

Solar Glass : 2.0mm High Transmission

Application : Aolar System for home

Max. Static Load : 5400P

Open-Circuit Voltage : 37.09-37.29V

Contact Now

Residential Energy Storage System 405W 415W Monocrystalline Solar Panel PERC Half Cell Solar Storage System



Solar Panel 405W 415W 410W Description
1. An 12-month product warranty

2. 25-years performance warrant + 0.55%Annual Degradation for Perc Mono-Module.

3. Corrosion-resistant aluminum material can withstand the changing outdoor environment and prolong its service life.

4. The front adopts a high-density battery arrangement, which makes it more beautiful in appearance. Maximum system voltage:1500VDC



405W 410W PV Panels Application:
Suitable for multiple scenarios such as: off grid system, home solar power system. Compatible with on-grid solar inverter and off grid solar inverter , powering the house or for outdoor use.



Mono Solar Panel System Configuration:

ELECTRICAL SPECIFICATION (STC)
Max-power 405 410 415
Power Tolerance 0~+6W
Voltage at Pmax (Vmp) 30.93 31.04 31.2
Current at Pmax (Imp) 13.10 13.21 13.3
Open-Circuit Voltage(Voc) 37.09 37.19 37.29
Short-Circuit Current (lsc) 13.98 14.07 14.16
Module Efficiency(%) 20.70 20.9 21.2
No. of Bypass Diodes(pcs.) 3
Max. Series Fuse(A) 25A
Operating Temperature - 45~+85 ℃
Max Static Load 5400P
Max-System Voltage(VDC) 1500 VDC(IEC)
Fire Rating Class C
STC: Irradiancec 1000W/m2, Cell Temperature 25 ℃,Air Mass 1.5

MECHANICAL SPECIFICATION
Solar cells Mono Crystalline 182×91 mm
108 Cell (6×18) — 10BB
Module Dimension(mm) 1722×1134×35
Weight 22.0 kg
Front Glass 2.0mm High Transmission.LowlronTempered Glass
Construction Encapsulation: EVA EVA /POE
Back Glass White
Junction Box IP68 Rated
Connector MC4/MC4 equivalent
Calble Φ=4mm2, L=300±5mm





FAQ:

Q: Could we import whoe solar energy system kits?
A: Yes. We are a manufacturer of solar system kits, such as energy storage battery, solar inverters and solar panels. Suitable for solar power generator systems



Q: How do you assure good quality products?
A: All of our solar panels 100% EL test before and after lamination, and finished products EL test, providing higher quality assurance.

Q: Is it possible to OEM customize the solar panels and the packaging with our logos?
A: Yes, OEM/customizing is warmly welcome for bulk orders. Just tell us your idea!


Residential Energy Storage System 405W 415W PERC Half CellResidential Energy Storage System 405W 415W PERC Half Cell
